    High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA

    Ask Lasest Price
    Brand Name : NOONDAY
    Model Number : AA8011/ AA1100/ AA3102
    Certification : RoHS/ISO9001/ASTM/JIS/GB/EN/ASTMB
    Payment Terms : L/C, T/T
    Supply Ability : 50, 000 Mt Per Year
    Delivery Time : according to specification and quantity
    • Product Details
    • Company Profile

    High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA

    High Performance Hydrophilic Aluminium Foil For Air Conditioning SGS TUV FDA​


    Hydrophilic aluminum foil occupies 80% volume of the air conditioner aluminum foil, compared with aluminum finstock, the surface of the aluminum foil with corrosion-free and hydrophilic layer, therefore it brings the aluminum foil with function of corrosion-free, anti-mildew agent and no off-flavor; also compared with finstock aluminum foil, its cooling efficient increased 5%, therefore it is more idea air conditioner heat exchange material. It can reduce the noise, guarantee the long & steady hot exchanger results of the air conditioner.


    Alloy: 1100/8011

    Temper: H22, HO

    Thickness: 0.08~0.2mm

    width: 100~1500mm

    Max. OD: 950mm max

    ID:75mm,152mm, 200mm,300mm,500mm


    Base AlloyBase temperthicknessmmTensile strength σb MPaRequires non-proportional extension strength N/mm2Elongation δ %Cupping Value IE mm
    1050 1100 120000.095-0.22085-110≥50≥20≥7.2
    H22100-130≥65≥18≥6.5
    H24115-140≥90≥16≥6.0
    H26125-155≥110≥10≥5.5
    H18≥160≥2
    80110105-130≥50≥22≥7.5
    H22115-140≥65≥20≥7.2
    H24125-150≥90≥16≥6.5
    H26130-160≥110≥12≥5.8
    H18≥180≥2
    3102H240.095-0.180120-140≥100≥15≥6.0
    H26130-160≥110≥10

    ≥5.5



    High Performance Hydrophilic Aluminium Foil , Aluminum Foil Roll SGS TUV FDA​ High Performance Hydrophilic Aluminium Foil , Aluminum Foil Roll SGS TUV FDA​


    Our advantages:
    1, Since 2008, we have rich experience in this industry in China;
    2, Good reputation in the production of aluminium/aluminum plate areas;
    3, We start our productions from aluminum ingot,so we can control the quality as well;
    4, We have our own development department for new material research;
    5, Good experience and cooperation with big clients in the world;
    6, With Certificate ISO9001-2008;
    7, High performance cost ratio;
    8, Fast delivery time;
    9, Customized orders available;
    10, Good communication skills, and good service and understandings for customers.
