    AA3003 Sliver Heavy Gauge Aluminum Foil Temper H24 Thickness 0.03-0.13mm

    Ask Lasest Price
    Brand Name : NOONDAY
    Model Number : Non Alloy
    Certification : RoHS/ISO9001/ASTM/JIS/GB/EN/ASTMB
    Payment Terms : L/C, T/T
    Supply Ability : 50, 000 Mt Per Year
    Delivery Time : according to specification and quantity
    • Product Details
    • Company Profile

    AA3003 Sliver Heavy Gauge Aluminum Foil Temper H24 Thickness 0.03-0.13mm

    NOONDAY CONTAINER FOIL SPECIFICATION


    Product Description


    PURPOSE

    To establish definitive quality standards on foil rolls, thereby minimizing claims attributable to any lack of understanding between supplier and customer.

    OBJECTIVE

    This specification covers 3003 alloy foil master rolls for container foil and describes the quality attributes of the master foil rolls.


    PHYSICAL REQUIREMENTS

    ALLOY AND TEMPER

    Alloy and temper should correspond to Table 1.


    Table 1

    AlloyTemper
    3003H24

    SPECIFICATION AND TOLERANCE

    The specification is as below Table 2.


    Table 2


    Gauge

    mm

    Gauge Tolerance

    mm

    Width

    mm

    Width Tolerance

    mm

    ID

    mm

    OD

    mm

    Core Material
    0.03~0.13±5%200~ 1200±1

    Æ 76.2

    Æ 150

    Æ 152

    600max to ID 76.2

    900max to ID 150 & 152


    Aluminium

    &

    Steel


    CHEMICAL COMPOSITION


    The chemical composition should correspond to Table 3.

    Table 3

    AlloySiFeCuMnZnOthersAl
    SingleTotal Up
    30030.60.70.05~0.201.0~1.50.100.050.15>99.35

    MECHANICAL PROPERTIES


    Mechanical properties should correspond to Table 4.

    Table 4

    AlloyTemper

    Gauge

    mm

    Tensile Strength

    Mpa

    Elongation

    %

    Erichsen

    mm

    3003H240.03~0.13140-190≥6.0≥4.5

    SURFACE CONDITION


    The surface shall be cleaned and free from inclusions, scratches, wrinkles, cracks, overlapping or other internal defects.


    Pin-holes


    The pin-holes should correspond to Table 5.

    Table 5

    Gauge0.030~0.0500.050~0.13
    Pinholes/m2300

    Spice

    The splices are as below Table 6.

    Table 6

    Gauge,mmSplices
    ≤0.06≤1
    >0.060

    a) All splices to be ultrasonic/tape.

    b) It is allowed one splice per roll. (Max. once per 2000m)

    c) Marked at the roll edge with a film, placed close to the splice.


    AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm Aluminium Foil AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm Aluminium Foil AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm Aluminium Foil

    Our advantages:
    1, Since 2008, we have rich experience in this industry in China;
    2, Good reputation in the production of aluminium/aluminum plate areas;
    3, We start our productions from aluminum ingot,so we can control the quality as well;
    4, We have our own development department for new material research;
    5, Good experience and cooperation with big clients in the world;
    6, With Certificate ISO9001-2008;
    7, High performance cost ratio;
    8, Fast delivery time;
    9, Customized orders available;
    10, Good communication skills, and good service and understandings for customers.
